Evolink Data Center Sofia 1
Location details
- Accessed via two main roads, 10 minutes from Sofia Airport:
- Shipchenski prohod Blvd.
- Tzarigradsko shosse Blvd.
- Located outside industrial area;
- Located outside residential area.
Building and premises characteristics
- Build of two monolithic iron-concrete structures placed one inside the other;
- Equipped with a loading platform;
- Situated at “minus 1” floor;
- No windows and no signs;
- Capacity – 220 sq. meters;
- Raised floor with load capacity for dispersed load 2000 kg per sq. meter;
- Raised floor with load capacity for point load 550 kg per sq. inch;
- Raised floor with fire resistance up to 60 minutes.
Rack/ Cabinet technical characteristics
- 19’ racks collocated equipment – communication or server racks;
- Power supply per rack – 2-6 kW;
Connectivity
- Connected via high-speed fiber links to more than 35 communication services providers;
Power supply redundancy
- Two UPS systems. They provide backup of the power supply for 60 minutes;
- 220 kW Diesel Power Generator. The generator provides backup of the power supply for unlimited time (as much as necessary);
Climate control
- Temperatures range 20-23 degrees Celsius;
- Humidity range –50-60 percent;
- Redundant Climate Control Systems, two systems whereas each one of the systems can independently support the entire data center;
- The power supply of the Climate Control Systems is reserved by the diesel generator;
Security
- Access card control system;
- 24x7 life guard security;
- Video surveillance with digital recording at the entrances/exits and the passages between the racks;
- Electronic security system;
Fire and flood detection systems
- Water detection system in the raised floor using sensor cable;
- Analogue-addressing fire-detection system covering the volumes under and over the raised floor with independent circles;
- Automated gas fire-extinguishing (flooding type) with extinguishing agent corresponding to EU standards - HFC227 (FM-200);
- Separate independent fire-detection system for the gas fire-extinguishing system;
- Fire resistant metal entrance/exit doors.
